Technical specifications
IP65, IK10, Surge protection 6KV. Operating temperature -30 °C to 60 °C. THD < 0.95. Lifetime 50,000 h. CCT: 3000K–5700K.
| Model | Power (W) | Size (mm) | Luminous Efficiency (lm/W) | Material | Driver | LED Type | CRI (Ra) | Beam Angle | IP Class |
|---|---|---|---|---|---|---|---|---|---|
| LUPH-100W-UFO-130LM | 100 | φ280 | 130 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-150W-UFO-130LM | 150 | φ330 | 130 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-200W-UFO-130LM | 200 | φ380 | 130 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-240W-UFO-130LM | 240 | φ380 | 130 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-100W-UFO-160LM | 100 | φ280 | 160 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-150W-UFO-160LM | 150 | φ330 | 160 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-200W-UFO-160LM | 200 | φ380 | 160 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-240W-UFO-160LM | 240 | φ380 | 160 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-100W-UFO-180LM | 100 | φ280 | 180 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-150W-UFO-180LM | 150 | φ330 | 180 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-200W-UFO-180LM | 200 | φ380 | 180 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
| LUPH-240W-UFO-180LM | 240 | φ380 | 180 | Alu. | Philips | SMD 2835 | 80 | 60° / 90° / 120° | IP65 |
