34degree UGR＜16 Reflective Cup Linear Light
Commercial Lighting
Features
- 34° UGR<16 Reflective Cup Linear Light
- Power: 40–120W, Efficiency: 100 or 130 lm/W
- LED: OSRAM, CRI: 85 or 90
- CCT: 3000 / 4000 / 6000K
- Beam Angle: 120° / 34°
- Dimming: 0–10V, DALI, PUSH, Motion sensor
- Colors: White, Black, Silver, Custom
Specifications
| Model | Power(W) | Size(mm) | Luminous Efficiency (lm/W) | LEDChips | CRI(Ra) | CCT(K) | BeamAngle | LightingDirection | Function | Finishing Color |
|---|---|---|---|---|---|---|---|---|---|---|
| LU-L3570D-UUR | 40W | 1200*35*70 | 100lm/Wor 130lm/W | OSRAM | 85or90 | 300040006000 | 120°/34° | |||
| LU-L3570C-DUR | 34° | |||||||||
| LU-L3570D-UUR | 50W | 100lm/Wor 130lm/W | OSRAM | 85or90 | 300040006000 | 120°/34° | On-Off;0/1-10V dimming;DALI dimming;PUSH dimming;Montion Sensor; | White;Black;Silver; Customized Color; | ||
| LU-L3570C-DUR | 34° | |||||||||
| LU-L3570D-UUR | 60W | 100lm/Wor 130lm/W | OSRAM | 85or90 | 300040006000 | 120°/34° | On-Off;0/1-10V dimming;DALI dimming;PUSH dimming;Montion Sensor; | White;Black;Silver; Customized Color; | ||
| LU-L3570C-DUR | 34° | |||||||||
| LU-L3570D-UUR | 40W | 1500*35*70 | 100lm/Wor 130lm/W | OSRAM | 85or90 | 300040006000 | 120°/34° | On-Off;0/1-10V dimming;DALI dimming;PUSH dimming;Montion Sensor; | White;Black;Silver; Customized Color; | |
| LU-L3570C-DUR | 34° | |||||||||
| LU-L3570D-UUR | 50W | 100lm/Wor 130lm/W | OSRAM | 85or90 | 300040006000 | 120°/34° | On-Off;0/1-10V dimming;DALI dimming;PUSH dimming;Montion Sensor; | White;Black;Silver; Customized Color; | ||
| LU-L3570C-DUR | 34° | |||||||||
| LU-L3570D-UUR | 60W | 100lm/Wor 130lm/W | OSRAM | 85or90 | 120°/34° | On-Off;0/1-10V dimming;DALI dimming;PUSH dimming;Montion Sensor; | White;Black;Silver; Customized Color; | |||
| LU-L3570C-DUR | 34° | |||||||||
| LU-L3570D-UUR | 60W | 1860*35*70 | 100lm/Wor 130lm/W | OSRAM | 85or90 | 300040006000 | 120°/34° | On-Off;0/1-10V dimming;DALI dimming;PUSH dimming;Montion Sensor; | White;Black;Silver; Customized Color; | |
| LU-L3570C-DUR | 34° | |||||||||
| LU-L3570D-UUR | 80W | 2400*35*70 | 100lm/Wor 130lm/W | OSRAM | 85or90 | 300040006000 | 120°/34° | On-Off;0/1-10V dimming;DALI dimming;PUSH dimming;Montion Sensor; | White;Black;Silver; Customized Color; | |
| LU-L3570C-DUR | 34° | |||||||||
| LU-L3570D-UUR | 120W | 100lm/Wor 130lm/W | OSRAM | 85or90 | 300040006000 | 120°/34° | On-Off;0/1-10V dimming;DALI dimming;PUSH dimming;Montion Sensor; | White;Black;Silver; Customized Color; | ||
| LU-L3570C-DUR | 34° | |||||||||
| LU-L3570D-UUR | 100W | 3000*35*70 | 100lm/Wor 130lm/W | OSRAM | 85or90 | 300040006000 | 120°/34° | On-Off;0/1-10V dimming;DALI dimming;PUSH dimming;Montion Sensor; | White;Black;Silver; Customized Color; | |
| LU-L3570C-DUR | 34° |
