LED Recessed Down Light LA078x LC078x
Commercial Lighting
Features
- Low consumption; more than 80% saving of the power
- Model: LA078EM / LA078ES / LA078I / LA078L / LA078M / LA078S / LA078XEM / LA078XI / LA078XM / LC078M-1 / LC078M-2 / LC078M-3
- Size(mm): 164x85x104 / 243x85x104 / 85x85x104 / Φ105x104 / Φ112x130 / Φ139x148 / Φ167x173 / Φ62x73 / Φ80x73 / Φ85x104
- Cutout(mm): 155x75 / 235x75 / 75x75 / Φ100 / Φ125 / Φ150 / Φ55 / Φ75
- Power(W): 25W/25W / 2x9W/2x15W / 30W/35W / 3x9W/3x15W / 40W/45W / 5W/7W / 9W/15W
- Lumen: 1050lm 15W / 1750lm 25W / 2100lm 2x15W / 2800lm 35W / 3150lm 3x15W / 3600lm 45W / 490lm 7W / 975lm 15W
- Material: Aluminum
- CCT: 3000K/4000K/5000K
- CRI(Ra): ≥90
- Beam Angle: 15°/24°/36°/50° / Polarized light
Specifications
| Model | Picture | Size(mm) | Cutout(mm) | Power(W) | Lumen | Material | CCT | CRI(Ra) | Beam Angle |
|---|---|---|---|---|---|---|---|---|---|
| LA078S | Φ62x73 | Φ55 | 5W/7W | 490lm 7W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° | |
| LA078M | Φ85x104 | Φ75 | 9W/15W | 1050lm 15W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° | |
| LA078L | Φ112x130 | Φ100 | 25W/25W | 1750lm 25W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° | |
| LA078I | Φ139x148 | Φ125 | 30W/35W | 2800lm 35W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° | |
| LA078XI | Φ167x173 | Φ150 | 40W/45W | 3600lm 45W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° | |
| LA078ES | Φ80x73 | Φ55 | 5W/7W | 490lm 7W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° | |
| LA078EM | Φ105x104 | Φ75 | 9W/15W | 1050lm 15W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° | |
| LA078XM | Φ85x104 | Φ75 | 9W/15W | 975lm 15W | Aluminum | 3000K/4000K/5000K | ≥90 | Polarized light | |
| LA078XEM | Φ105x104 | Φ75 | 9W/15W | 975lm 15W | Aluminum | 3000K/4000K/5000K | ≥90 | Polarized light | |
| LC078M-1 | 85x85x104 | 75x75 | 9W/15W | 1050lm 15W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° | |
| LC078M-2 | 164x85x104 | 155x75 | 2x9W/2x15W | 2100lm 2x15W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° | |
| LC078M-3 | 243x85x104 | 235x75 | 3x9W/3x15W | 3150lm 3x15W | Aluminum | 3000K/4000K/5000K | ≥90 | 15°/24°/36°/50° |
