LED Flood Light FLB Series
Industry Lighting
Features
- Model: LU-FLB series (50–800W)
- Power: 50–800W
- Luminous Flux: 5000–80000 lm
- Material: Die-cast Aluminum
- Driver: MeanWell
- CRI: >70, CCT: 3000 / 4000 / 6000K
- Beam Angle: 60° / 120°
- IP65
Specifications
| Model | Power(W) | Size(mm) | Luminous Flux(lm) | Material | Driver | LED Type | CRI(Ra) | CCT(K) | BeamAngle | IP Class |
|---|---|---|---|---|---|---|---|---|---|---|
| LU-FLB-50W | 50 | 209×202×31 | 5000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-50W*2 | 100 | 418×202×31 | 10000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-50W*4 | 200 | 418×404×31 | 20000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-50W*6 | 300 | 418×608×31 | 30000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-50W*8 | 400 | 819×404×31 | 40000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-100W | 100 | 220×270×34 | 10000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-200W | 200 | 455×237×56 | 20000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-200W*2-A | 400 | 455×474×56 | 40000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-200W*2-B | 400 | 915×237×56 | 40000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-200W*3 | 600 | 715×455×56 | 60000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-200W*4-A | 800 | 955×455×56 | 80000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-200W*4-B | 800 | 455×915×56 | 80000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-300W | 300 | 670×236×56 | 30000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
| LU-FLB-300W*2 | 600 | 474×670×56 | 60000 | Die-cast Aluminum | MeanWell | SMD | >70 | 3000 4000 6000 | 60° / 120° | IP65 |
