LED GL Series
Outdoor Lighting
Features
- Low consumption; more than 80% saving of the power
- Long lifetime 50,000 hours
- Aluminum extrusion with good heat-dissipation
- Water-proof, Dust-proof, Damp-proof, IP66
- High luminous efficacy 130 lm/W or 150 lm/W
- IK10
- Driver: Meanwell / Hahga, LED: SMD 3030 Philips
Specifications
| Model | Power(W) | Size(mm) | Luminous Efficiency (lm/W) | Material | Driver | LED Type | CRI(Ra) | CCT(K) | IK | IP Class |
|---|---|---|---|---|---|---|---|---|---|---|
| LU-GL-20W | 20W | 400×815 | 130/150 | AL | Meanwell/Hahga | SMD 3030 Philips | 80 | 3000–6000 | IK10 | IP66 |
| LU-GL-30W | 30W | 400×815 | 130/150 | AL | Meanwell/Hahga | SMD 3030 Philips | 80 | 3000–6000 | IK10 | IP66 |
| LU-GL-40W | 40W | 400×815 | 130/150 | AL | Meanwell/Hahga | SMD 3030 Philips | 80 | 3000–6000 | IK10 | IP66 |
| LU-GL-50W | 50W | 400×815 | 130/150 | AL | Meanwell/Hahga | SMD 3030 Philips | 80 | 3000–6000 | IK10 | IP66 |
| LU-GL-60W | 60W | 400×815 | 130/150 | AL | Meanwell/Hahga | SMD 3030 Philips | 80 | 3000–6000 | IK10 | IP66 |
| LU-GL-80W | 80W | 400×815 | 130/150 | AL | Meanwell/Hahga | SMD 3030 Philips | 80 | 3000–6000 | IK10 | IP66 |
| LU-GL-100W | 100W | 400×815 | 130/150 | AL | Meanwell/Hahga | SMD 3030 Philips | 80 | 3000–6000 | IK10 | IP66 |
| LU-GL-120W | 120W | 400×815 | 130/150 | AL | Meanwell/Hahga | SMD 3030 Philips | 80 | 3000–6000 | IK10 | IP66 |
